EN
| Model | M-2000W-12V | M-2000W-24V | M-2000W-48V |
| Output Power | 2000W | ||
| Peak Power | 4000W | ||
| DC Input Voltage Range | DC12V(9.5V-15.5V) | DC24V(19V-31V) | DC48V(38V-62V) |
| AC Output Voltage (Single Choice) | 100V/110V/120V/220V/230V/240V | ||
| Unload Current | ≤0.6A | ≤0.4A | ≤0.25A |
| Output Frequency | （50Hz±2Hz） or（ 60Hz±2Hz） | ||
| Output Waveform | Modified sine wave | ||
| Display | LED or LCD display | ||
| USB Output Votlage / Current | 5V 2A (Support QC3.0 fast charge up to 18W) | ||
| Max. Output Efficiency | 88% | 90% | 92% |
| Low Voltage Protection | Alarm “Bi” with 2s interval +red and green lights flashing alternately / restart automatically when voltage recover |
||
| Over Voltage Protection | Alarm “BiBi” with 1s interval +red and green lights flashing alternately / restart automatically when voltage recover |
||
| Over Load Protection | Alarm “Bi” continously +red light flashing / restart automatically when load power recover; If it is closed after twice recover, it need restart manually. |
||
| Over Temp Protection | Alarm “BiBiBi” with 1s interval +red and green lights flashing alternately / restart when temp recover |
||
| Short Circuit Protection | yes | ||
| DC Reverse Connection Protection | Fuse burnt | ||
| Low Voltage Alarm Range | 10.5v±0.5v | 21v±0.5v | 42v±0.5v |
| Low Voltage Protection Range | 9.5v±0.5v | 19v±0.5v | 38v±0.5v |
| Low Voltage Recover Range | 12v±0.5v | 23v±0.5v | 46v±0.5v |
| Over Voltage Protection Range | 15.5v±0.5v | 31v±0.5v | 62v±0.5v |
| Over Voltage Recover Range | 14v±0.5v | 28v±0.5v | 56v±0.5v |
| Working Temperature | -10℃~50℃ | ||
| Cooling Method | Fan cooling (Temperature control) | ||
| Note: The tech updates constantly. These datas are used for reference only. Please refer to our real product. | |||
1. LED indicates load status
2. Soft start, effectively maintain battery life
3. Overload/short circuit protection
4. Overvoltage/undervoltage protection
5. OEM and ODM are available, and the shell color can be customized.
6. High Inrush: High inrush current capability to start difficult loads.
7. Grounding protection: There are terminals on the front panel to ground the inverter.
8. The cooling fan in the inverter is thermally activated, starts when the inverter gets hot, and turns off automatically when the inverter cools down.
Home Backup Power: Power inverters can be used to provide backup power during a power outage. They can be connected to a battery pack or generator to provide continuous power to appliances.
Solar Photovoltaic Applications: Power inverters are used to convert the direct current generated by solar panels into alternating current that can be used to power homes and businesses.
Industrial Applications: Power inverters are used in a variety of industrial applications such as powering conveyor belts, pumps, and other machinery.
Mobility in Vehicles: Power inverters are commonly used in mobility vehicles to power electronic devices such as laptops, cell phones, and GPS devices.
Hisolar (ZHEJIANG JINGYING NEW ENERGY),specializing in the production of power inverters, hybrid solar inverter, customized inverter PCB boards, and other clean energy solutions.
