500W Pure Sine Wave UPS Inverter — Clean Power Backup with Built-in Charger & ATS

The JYINS 500W Pure Sine Wave UPS Inverter delivers clean, grid-quality AC power for sensitive electronics during outages. Featuring pure sine wave output (THD < 3%), built-in intelligent battery charger, and automatic transfer switch (ATS) with < 10ms switchover, it protects computers, medical equipment, communication devices, and home entertainment systems. The compact design supports 12V/24V external battery systems for flexible runtime configuration.

Brand:

Jyins

Appurtenance:

500w pure sine wave ups inverter clean power backup with built in charger ats-2

Product Description

Parameter	Specification
Model	JYPU-500 Series
Rated Power	500W Continuous
Peak Power	1000W
DC Input Voltage	12V / 24V DC
AC Output Voltage	110V/120V or 220V/230V/240V AC
AC Input Voltage	90–135V AC or 190–260V AC
Output Waveform	Pure Sine Wave (THD < 3%)
Output Frequency	50Hz / 60Hz ± 0.5Hz
Max Efficiency	> 90%
Transfer Time	< 10ms (UPS Mode)
Charging Current	10A / 15A
USB Output	5V 1A
Protection	Low/High Voltage, Overload, Short Circuit, Over-temp, Reverse Polarity
Dimensions	230 × 180 × 130 mm
Weight	~2.5 kg

Performance Advantages

True pure sine wave output — identical to grid power, safe for all sensitive electronics
THD < 3% — ultra-clean waveform protects computers, medical devices, and audio equipment
Built-in 3-stage intelligent charger — bulk, absorption, and float charging for longer battery life
< 10ms UPS transfer — no reboot needed for computers, routers, and servers
Compatible with all battery types — LiFePO4, lead-acid, AGM, gel with configurable charging
Compact and lightweight — easy wall mounting or desktop placement
Quiet operation with smart temperature-controlled cooling fan

Application Scenarios

Home Office — Protects desktop PC, NAS, router, and modem from power interruptions
Medical Equipment — Clean power for CPAP machines, oxygen concentrators, and small medical devices
Audio & Entertainment — Noise-free power for hi-fi systems, home theater, and gaming consoles
Communication Systems — Backup for VoIP phones, network switches, and small servers
Laboratory Equipment — Stable power for sensitive measurement and testing instruments
Smart Home — Keeps security systems, smart hubs, and automation controllers running

Why Choose JYINS

Zhejiang Jingying (JYINS) Electrical Co., Ltd., established in 1993, is a leading manufacturer with over 30 years of expertise in power inverters, solar charge controllers, energy storage systems, and renewable energy solutions. Our 500+ employee factory in Wenzhou, China, serves clients across 50+ countries with ISO9001/CE/SAA/RoHS certified products.

30+ years of manufacturing excellence since 1993
ISO9001, ISO14001, ISO45001, CE, SAA, RoHS, FCC certified
Dedicated R&D center with 30+ national patents
OEM/ODM services with flexible MOQ and fast prototyping (7-10 days samples)
Export to 50+ countries across 6 continents
Professional pre-sales engineering support and after-sales service

Frequently Asked Questions (FAQ)

Q: Is pure sine wave really necessary for my devices?

A: For computers, servers, medical equipment, audio gear, and anything with AC motors — yes. Modified sine wave can cause buzzing, overheating, or malfunction in sensitive electronics.

Q: How long will a 100Ah battery last?

A: At 500W full load: ~1.8 hours (12V 100Ah). At typical 200W load: ~4.5 hours. LiFePO4 batteries provide more usable capacity than lead-acid.

Q: Can I leave it plugged in 24/7 like a standard UPS?

A: Yes, the unit is designed for continuous operation. It passes through grid power normally and automatically switches to battery during outages.

Q: Does it work as a solar inverter too?

A: With an external solar charge controller connected to the battery bank — yes. The unit draws from the battery which is charged by solar.
