455W Frameless Bifacial Solar Panel — 31.94V Ultra-Modern Glass-Glass Dual-Glass PV Module

The JYINS 455W Frameless Bifacial Solar Panel (LS-F455M) represents the cutting edge of solar PV design with its sleek frameless, dual-glass construction. This innovative module eliminates the traditional aluminum frame, using two layers of 2.0mm tempered glass for superior durability, fire resistance, and aesthetic appeal. With 455W output at 31.94V Vmp and a bifacial design capturing reflected light, it delivers more power per square meter than conventional framed panels. Ideal for modern architectural installations, carports, and premium residential projects.

Brand:

Jyins

Appurtenance:

455w frameless bifacial solar panel 3194v ultra modern glass glass dual glass pv module-2

Product Description

Parameter	Specification
Model	LS-F455M
Maximum Power (Pmax)	455W
Maximum Power Voltage (Vmp)	31.94V
Maximum Power Current (Imp)	14.25A
Open Circuit Voltage (Voc)	38.6V
Short Circuit Current (Isc)	15.10A
Cell Type	Monocrystalline PERC Half-Cut Bifacial
Cell Configuration	144 Half-Cells
Bifaciality Factor	70% ± 5%
Front Glass	2.0mm Tempered Anti-Reflective Coated
Rear Glass	2.0mm Tempered (Transparent)
Frame	Frameless (Glass-Glass Construction)
Junction Box	IP68 Rated, Slim Profile
Dimensions	2094 x 1038 x 5 mm (Double Glass)
Weight	24.0 kg
Max System Voltage	1500V DC
Warranty	30-Year Linear Power Output Warranty

Performance Advantages

Frameless glass-glass construction — eliminates frame corrosion, PID (Potential Induced Degradation), and frame grounding requirements
30-year linear power warranty — extended lifespan compared to standard 25-year framed panel warranties
455W high output at lower 31.94V Vmp — more panels per string for optimized inverter utilization
144 half-cut bifacial cells — superior shade tolerance with 3 bypass diode sections
Dual 2.0mm tempered glass — Class A fire rating, higher mechanical load capacity, no micro-crack propagation
Sleek frameless appearance — premium aesthetic for architectural, carport, and visible installations
Better thermal coefficient — glass-glass construction dissipates heat more evenly, improving hot-weather performance

Application Scenarios

Architectural Solar — Premium aesthetic for visible building-integrated and facade installations
Solar Carports — Sleek frameless panels complement modern parking structure designs
Agricultural Greenhouses — Partial light transmission for crop-friendly agrivoltaic installations
High-End Residential — Premium appearance for luxury home solar installations
Ground-Mount Commercial — Extended 30-year warranty for long-term ROI commercial projects
Coastal & Corrosive Environments — Frameless design eliminates aluminum frame corrosion in salt-spray zones

Why Choose JYINS

Zhejiang Jingying (JYINS) Electrical Co., Ltd., established in 1993, is a leading manufacturer with over 30 years of expertise in power inverters, solar charge controllers, energy storage systems, and renewable energy solutions. Our 500+ employee factory in Wenzhou, China, serves clients across 50+ countries with ISO9001/CE/SAA/RoHS certified products.

30+ years of manufacturing excellence since 1993
ISO9001, ISO14001, ISO45001, CE, SAA, RoHS, FCC certified
Dedicated R&D center with 30+ national patents
OEM/ODM services with flexible MOQ and fast prototyping (7-10 days samples)
Export to 50+ countries across 6 continents
Professional pre-sales engineering support and after-sales service

Frequently Asked Questions (FAQ)

Q: Is frameless less durable than framed?

A: Actually, frameless glass-glass panels are MORE durable. They eliminate frame-related corrosion and PID issues. The dual-glass construction provides superior mechanical strength and a 30-year warranty vs standard 25-year.

Q: How do you mount frameless panels?

A: Using specialized clamps designed for glass-glass modules. These clamps grip the glass edge with protective EPDM rubber pads. Compatible with most standard mounting rail systems.

Q: Why choose frameless over traditional framed panels?

A: Frameless offers: longer warranty (30yr), no PID degradation, no frame corrosion, better fire rating, sleeker appearance, and generally better long-term reliability. The cost premium is typically 5-10%.

Q: Do they produce more power than framed panels?

A: At the same wattage rating, energy output is similar. However, the better thermal characteristics and lack of PID can result in 2-5% more annual energy production over the system lifetime.
