320W MC4 Polycrystalline Solar Panel — Reliable Poly PV Module for Residential & Commercial

The JYINS 320W MC4 Polycrystalline Solar Panel offers proven reliability and cost-effective solar power generation for residential, commercial, and off-grid installations. Featuring 72 high-efficiency polycrystalline silicon cells with MC4-compatible connectors, it delivers consistent performance with excellent low-light response. The corrosion-resistant anodized aluminum frame and IP65 junction box ensure decades of durable outdoor operation. Ideal for budget-conscious solar projects without compromising on quality or warranty coverage.

Brand:

Jyins

Appurtenance:

320w mc4 polycrystalline solar panel reliable poly pv module for residential commercial-2

Product Description

Parameter	Specification
Model	LS-P320M
Maximum Power (Pmax)	320W
Module Efficiency	16.5%
Cell Type	Polycrystalline Silicon (72 Cells)
Maximum Power Voltage (Vmp)	37.2V
Maximum Power Current (Imp)	8.60A
Open Circuit Voltage (Voc)	45.5V
Short Circuit Current (Isc)	9.15A
Power Tolerance	0 ~ +5W (Positive Tolerance Only)
Front Glass	3.2mm High-Transmission Tempered Glass
Frame	Silver Anodized Aluminum Alloy
Junction Box	IP65 Rated with MC4 Compatible Connectors
Connector Type	MC4 Compatible
Output Cables	4.0 mm², Length 900mm
Dimensions	1956 x 992 x 40 mm
Weight	22.5 kg
Max System Voltage	1000V DC
Warranty	10-Year Product / 25-Year Linear Power

Performance Advantages

Proven polycrystalline technology — mature, reliable cell technology with decades of field performance history
Positive power tolerance (0~+5W) — every panel guaranteed to meet or exceed rated power, never below
72-cell high-voltage design — optimized for grid-tied string inverters with higher MPPT voltage range
MC4 compatible connectors — industry-standard quick-connect system for fast, reliable field installation
IP65 junction box with bypass diodes — minimizes power loss from partial shading and prevents hot spots
Corrosion-resistant aluminum frame — rated for high wind (2400Pa) and snow load (5400Pa)
Excellent low-light performance — polycrystalline cells maintain better output in cloudy and diffuse light conditions

Application Scenarios

Residential Rooftop Solar — Affordable high-power panels for grid-tied home solar systems
Commercial Solar Installations — Cost-effective PV for warehouses, factories, and office buildings
Solar Farms — Utility-scale ground-mount installations with competitive LCOE
Off-Grid Home Systems — Reliable power for remote homes with battery storage
Agricultural Solar — Barn, greenhouse, and farm building rooftop installations
Solar Water Pumping — Dedicated PV arrays for irrigation and livestock water systems

Why Choose JYINS

Zhejiang Jingying (JYINS) Electrical Co., Ltd., established in 1993, is a leading manufacturer with over 30 years of expertise in power inverters, solar charge controllers, energy storage systems, and renewable energy solutions. Our 500+ employee factory in Wenzhou, China, serves clients across 50+ countries with ISO9001/CE/SAA/RoHS certified products.

30+ years of manufacturing excellence since 1993
ISO9001, ISO14001, ISO45001, CE, SAA, RoHS, FCC certified
Dedicated R&D center with 30+ national patents
OEM/ODM services with flexible MOQ and fast prototyping (7-10 days samples)
Export to 50+ countries across 6 continents
Professional pre-sales engineering support and after-sales service

Frequently Asked Questions (FAQ)

Q: Poly vs Mono — which should I choose?

A: Poly panels are 10-15% cheaper per watt and perform better in hot/cloudy conditions. Mono panels are more efficient (use less roof space). Choose poly for budget projects and mono for space-constrained roofs.

Q: How many panels for a 5kW system?

A: 16 panels (16 x 320W = 5,120W). Array requires approximately 32 m² of roof space. Compatible with most 5kW single-phase string inverters.

Q: Are MC4 connectors included?

A: Yes, each panel comes with pre-attached MC4 compatible cables and connectors for simple series connection between panels.

Q: Can these be used with microinverters?

A: Yes, 320W poly panels work with most microinverters rated for 60-cell or 72-cell modules. Check microinverter specifications for voltage and current compatibility.
