200w Solar Folding BagIP65 Solar Folding Bag200watt solar powered back pack |
Model | LS-B200M |
Maximum Power(Pmax) | 200W (8x25W) |
Maximum Power Voltage(Vmp) | 20.52V |
Maximum Power Current(Imp) | 9.75A |
Open Circuit Voltage(Voc) | 24.01V |
Short Circuit Current(Isc) | 10.42A |
Power Tolerance(Positive) | ± 3% |
Cell Type | Monocrystalline cell |
Contract Dimensions(mm) |
Product Dimension(Folded):420*465*60mm Product Dimension(Open):1900*840*5mm |
Weight(KGS) | 7.5kg |
Protection Class | IP65 |
Maximum System Voltage | 60V |
Temperature Range | -20°C - 85°C |
Standard Test Conditions | 1000W/m2, AM1.5, 25°C |
Q1:What's the solar panels warranty?
A: 5 year's warranty.If you have any questions about our quality during use,you can contact us at any time.
Q2:Do you accept OEM/ODM orders?
A:We accept OEM/ODM orders.Welcome your inquiry.
Q3:Can I have samples to test?and what's the lead time for the sample order?
A:Yes,of course.The lead time for samples is 7-10 days.
Q4:Where are your goods exported?
A:We can export to all over the world.
