100-300Ah LiFePO4 Lithium Battery — Smart BMS Deep-Cycle Battery for Solar RV Marine

The JYINS 100-300Ah LiFePO4 (Lithium Iron Phosphate) Battery delivers premium deep-cycle energy storage for solar, RV, marine, and off-grid applications. Available in 100Ah, 200Ah, and 300Ah capacities at 12.8V nominal, these batteries feature an intelligent built-in BMS (Battery Management System) with comprehensive protection against overcharge, over-discharge, short circuit, and temperature extremes. With 4000-6000 cycle life at 80% DOD, they outlast lead-acid batteries by 8-10x while weighing 60% less. Expandable in series (up to 48V) and parallel configurations.

Product Description

Parameter	Specification
Model Series	JY-LFP Series
Nominal Voltage	12.8V DC
Capacity Options	100Ah (1280Wh) / 200Ah (2560Wh) / 300Ah (3840Wh)
Cell Chemistry	LiFePO4 (Lithium Iron Phosphate) — Grade A Cells
Cycle Life	4000-6000 Cycles at 80% DOD (80% Capacity Retention)
BMS Protection	Overcharge, Over-discharge, Over-current, Short Circuit, Temperature, Cell Balancing
Max Continuous Discharge	100A (100Ah); 200A (200-300Ah)
Peak Discharge (3s)	200A (100Ah); 400A (200-300Ah)
Charge Voltage	14.2V - 14.6V
Charge Current	50A Recommended (100Ah); 100A (200-300Ah)
Self-Discharge	< 3% per Month
Operating Temperature	Charge: 0℃ to 45℃; Discharge: -20℃ to 60℃
Series Connection	Up to 4 in Series (48V)
Parallel Connection	Up to 4 in Parallel
Weight	~11 kg (100Ah); ~22 kg (200Ah); ~33 kg (300Ah)
Dimensions (100Ah)	330 x 172 x 215 mm
Warranty	5 Years

Performance Advantages

4000-6000 cycle life — over 10 years of daily use, 8-10x longer than lead-acid batteries
Grade A LiFePO4 cells — UL certified cells with consistent capacity and internal resistance matching
Smart BMS with cell balancing — active balancing maintains all cells at equal voltage, maximizing usable capacity
60% lighter than lead-acid — a 100Ah LiFePO4 weighs just 11 kg vs 28 kg for equivalent AGM
100% usable capacity — unlike lead-acid (50% recommended DOD), use the full rated capacity without damage
Flat discharge curve — maintains > 12.8V through 90% of discharge, unlike lead-acid voltage sag
Expandable design — connect in series for 24V/36V/48V or parallel for larger capacity banks

Application Scenarios

RV & Camper House Batteries — Lightweight high-capacity power for extended off-grid camping
Marine & Yacht — Safe LiFePO4 chemistry with no off-gassing for enclosed boat compartments
Home Solar Storage — Daily cycling for residential off-grid and hybrid solar systems
Golf Carts & EVs — Drop-in replacement for lead-acid with 3x range and half the weight
Trolling Motors — Consistent voltage throughout discharge for all-day fishing performance
UPS Backup — Long-life replacement for lead-acid UPS battery banks with zero maintenance

Why Choose JYINS

Zhejiang Jingying (JYINS) Electrical Co., Ltd., established in 1993, is a leading manufacturer with over 30 years of expertise in power inverters, solar charge controllers, energy storage systems, and renewable energy solutions. Our 500+ employee factory in Wenzhou, China, serves clients across 50+ countries with ISO9001/CE/SAA/RoHS certified products.

30+ years of manufacturing excellence since 1993
ISO9001, ISO14001, ISO45001, CE, SAA, RoHS, FCC certified
Dedicated R&D center with 30+ national patents
OEM/ODM services with flexible MOQ and fast prototyping (7-10 days samples)
Export to 50+ countries across 6 continents
Professional pre-sales engineering support and after-sales service

Frequently Asked Questions (FAQ)

Q: Can I replace my lead-acid battery directly with this?

A: Yes, for most 12V applications. However, ensure your charger has a LiFePO4 profile (14.2-14.6V absorption). Standard lead-acid chargers may not fully charge lithium batteries.

Q: How long will a 100Ah battery last running a 12V fridge?

A: A typical 12V portable fridge draws 3-5A cycling. A 100Ah LiFePO4 provides approximately 20-30 hours of runtime (depending on ambient temperature and fridge settings).

Q: Can I connect these in series for 24V/48V?

A: Yes, up to 4 batteries in series for 48V systems. Use identical batteries (same model, capacity, and age) in series strings for balanced charging.

Q: Is LiFePO4 safe for indoor installation?

A: Yes, LiFePO4 is the safest lithium chemistry — no thermal runaway, no fire risk, no toxic gas emission. It's approved for indoor installation in living spaces.
